Name: MARS Dual Stadium Antenna Mount 13dBi 698-2700MHz Mount
SKU: 1569197

Home Hi-Fi Systems Wireless Hi-Fi Systems

MARS Dual Stadium Antenna Mount 13dBi 698-2700MHz Mount

Product Details ＋

MARS new DUAL BAND and DUAL POL antenna specially designed for arenas and stadiums that have to supply high capacity and reliable wireless data.

MARS MA-WA82220-DBDP14 provides solutions for services such as LTE Cellular (2G 2.5G and 3G) Wi-Fi and WiMAX applications. The antenna is PIM certified thus making it suitable for all multi-carrier systems.

Provides a 12dBi gain for 698-960MHz
Provides a 13dBi gain for 1700-2700MHz

Additional Features:

Efficient and stable performance with 12-13 dBi of gain.
UV protected radome suitable for harsh environment installations
Durable construction
Easy mounting allowing Az/El adjustment
Aesthetic design
Weatherized and durable
Wind survival rating of 200 km/h

ELECTRICAL SPECIFICATIONS

Frequency Range:	698-960 / 1710-2700 MHz
Gain Vertical Pol.:	12/13 dBi
Gain Horizontal Pol.:	13/13 dBi
VSWR max.:	2.0 : 1
Polarization:	dual-pol “ Vertical & Horizontal
3 dB Beam-Width	Azimuth typ.: 35°/35°
3 dB Beam-Width	Elevation typ.: 35°/35°
Front to Back Ratio min.:	-22 dB
Input power max.:	50 Watt
Port to Port Isolation min.:	-22 dB/-37 dB
Input Impedance:	50 Ohm
PIM 3rd order 2X20W:	-150 dBc

MECHANICAL SPECIFICATIONS

Dimensions (HxWxD):	800 x 600 x 110 mm (31.5 ³ x 23.6 ³ x 4.33 ³)
Weight:	6 Kg
Connector:	2 x N-type Female
Back Plane:	Aluminium protected through chemical passivation.
Radome:	UV Protected Plastic
Mounting	MNT-25 mount

ENVIRONMENTAL SPECIFICATIONS

Operating Temp Range:	55°C to 65°C
Wind Load:	200 Km/h (Survival)
Vibration:	According to IEC 60721-3-4
Flammability:	UL94
Water Proofing:	IP-67
Salt Fog:	According to IEC 68-2-11
Humidity:	ETS 300 019-1-4 EN 302 085 (Annex A.1.1)
