Product Details
+
- Intermittent or continuous sound options
- Nominal Voltage: 12 V / 24 V
- Operating Voltage: 9 – 28 V
- Maximum Current: 500 mA
- Sound frequency: 3.5 kHz
- Sound Pressure Level: 105dB at 30cm
- Tone/Pulse Rate: Constant
- Protection class: IP 68 front side, IP 52 rear side acc. IEC60529
- Housing: Ø52 mm – Polycarbonate (PC)
- Installation depth: 50 mm
- Bezel: PC (black)
- Operating temperature: -30°C to 80°C
- Storage temperature: -40°C to 85°C
- Flammability: flame retardant acc. UL94-V0
- Connector: Tyco / Hirschmann MQS connector 8 pins
- Mounting: Spinlock Nut – locking height 0.5 – 20 mm
- Optional Studs and Brackets – locking height 2 – 15 mm
- Certifications CE, Reach, RoHS
