ZZ9A2 Wiggins Fast Fueling Systems | Hi-Flow Diesel Refueling Nozzle with Automatic Shut-Off - Fast Fuel Nozzles

2" NPT Plastic Quick Fill Nozzle, 211 GPM, New

FEATURES:

• Industry-standard diesel refueling nozzle
• 211 gpm (800 lpm) maximum flow rate
• 2" NPT female inlet thread
• Durable, dependable Elast-O-Dog latching
• Used in many mining and heavy construction sites where multiple pieces of rolling stock as well as stationery equipment is present
• High Flow rate fueling nozzle for larger fuel tanks where faster fuel times are required
• Mates with the  (pressurized platform) and JNX (non-pressurized platform) receivers
• Automatic shutoff; works with pressurizing and non-pressurizing systems
• Field-replaceable components: , ,

TECHNICAL SPECS:

• Minimum Flow Rate - 25 gpm (95 lpm)
• Maximum Flow Rate - 211 gpm (800 lpm)
• Operating Pressure - 75 psig (520 kPa)
• Weight - 5.64 lbs (2.56 kg)
